钢结构阳光房搭建步骤有哪些?

来源:http://www.lxcaigang.com 日期:2023-09-11 发布人:
一:钢结构的除锈、刷防锈漆,在阳光房的钢结构焊接前,所有的方管应做好防锈处理,保证钢结构不易锈蚀。
1: Before welding the steel structure in the sunlight room, all square pipes should undergo rust prevention treatment to ensure that the steel structure is not prone to rusting.
二::焊接主体结构用规格为80mm*80mm,壁厚为3mm的方钢,按照测量尺寸和设计要求焊接四角立柱,以及四边圈梁,作为整个阳光房的主体承重结构。立柱的垂直度及立柱与立柱之间的距离误差不应超过正负5MM。
2: The main structure of the welding is made of 80mm * 80mm square steel with a wall thickness of 3mm. The four corner columns and four side ring beams are welded according to the measurement dimensions and design requirements as the main load-bearing structure of the entire sunlight room. The verticality of the column and the distance error between the column and the column should not exceed plus or minus 5mm.
三:焊接主梁及副梁用规格为76mm*44mm,壁厚为2.5mm的方钢钢,按照顶面的设计,合理分布横梁和纵梁,从美观、承重等各方面衡量,焊接顶部结构。这里可以按实际需要,选用不同壁厚和规格的方管。在焊接时,钢结构的连接处必须焊点饱满,无假焊,不松动,无縫隙,好的焊接方式是鱼鳞焊接。
禹城钢结构板房
3: The main and auxiliary beams are welded using square steel with a specification of 76mm * 44mm and a wall thickness of 2.5mm. According to the design of the top surface, the beams and longitudinal beams are reasonably distributed, and the top structure is welded from various aspects such as aesthetics and load-bearing. Here, square tubes with different wall thicknesses and specifications can be selected according to actual needs. When welding, the connection of the steel structure must have full solder joints, no false welds, no looseness, and no gaps. A good welding method is fish scale welding.
四:钢结构的美化钢结构焊接好之后,可以用1.2mm厚的不锈钢板按照钢材的尺寸进行折边,把方钢全部包裹起来。这样,既能防止钢结构的风吹雨淋和磕碰刮擦,又增加了它的美观性。有一部分人出于成本的考虑,不进行包裹,而是在方钢上做油漆处理,这样也可以,但是一般每两年要对方钢维护一次,比较麻烦。
4: After the beautification of the steel structure is welded, a 1.2mm thick stainless steel plate can be folded according to the size of the steel to wrap all the square steel. This not only prevents the steel structure from being exposed to wind, rain, and scratches, but also enhances its aesthetics. Some people, due to cost considerations, do not package and instead apply paint treatment to the square steel. This is also acceptable, but it usually requires maintenance on the square steel every two years, which is quite troublesome.
五:阳光房盖顶按照焊接好的钢结构,制作安装阳光房的顶面材料,可以选用彩钢板,阳光板,单面钢化玻璃或者中空钢化玻璃,承重及抗击能力好的,要数夹胶玻璃。单面钢化玻璃可以采用8mm一12mm厚,或者5mm+9A+5mm的中空钢化玻璃,彩钢板可以使用80mm或者120mm厚,带瓦楞的彩钢板。
5: The roof of the sunlight room is made of welded steel structure, and the top material for installing the sunlight room can be color steel plate, sunlight board, single-sided tempered glass or hollow tempered glass. For those with good load-bearing and resistance, laminated glass is required. Single sided tempered glass can be 8mm to 12mm thick, or 5mm+9A+5mm hollow tempered glass. Color steel plates can be 80mm or 120mm thick, corrugated color steel plates.
步骤六:制作安装立面门窗阳光房的立面门窗可以选择铝合金门窗,断桥铝合金门窗,木包铝门窗或者纯实木门窗等。
Step 6: To create and install facade doors and windows for the sunlight room, you can choose aluminum alloy doors and windows, bridge cut aluminum alloy doors and windows, wood clad aluminum doors and windows, or pure solid wood doors and windows.
