济南活动板房的施工步骤的详细介绍

来源:http://www.lxcaigang.com 日期:2020-08-19 发布人:
对于活动板房,大多数人会比较陌生,而在现代建筑中,却因其独特的优势被广泛采用。活动板房也分为不同的种类,较常用的为彩钢活动房。接下来济南活动板房厂家就为大家详细介绍一下。
Most people are unfamiliar with prefabricated houses, but they are widely used in modern buildings because of their unique advantages. The activity plank room also divides into the different kind, the more commonly used is the color steel activity room. Next, Jinan mobile panel house manufacturers will give you a detailed introduction.
这种活动房的墙体与屋面材料均为彩色钢板覆面聚苯乙烯泡沫塑料夹芯复合板。彩钢夹芯板具有保温隔热、防腐隔音、轻质阻燃、抗震性能好、坚固美观、安装方便、有效增加房屋的使用面积以及无需二次装修等特点。彩钢活动房的结构稳定可靠,屋面采用结构防水设计,不需另做任何防水处理。内外墙与屋面色泽明艳、质感柔和、板面平整,与房屋钢骨架非常和谐,具有很好的装饰效果,房屋内部的可装饰性也很强。
The walls and roofing materials of the movable rooms are all colored steel plate covered polystyrene foam sandwich panels. Color steel sandwich panel has the characteristics of thermal insulation, anti-corrosion and sound insulation, light flame retardant, good seismic performance, strong and beautiful, convenient installation, effective increase of the use area of the house and no need for secondary decoration. The structure of the color steel activity room is stable and reliable, and the roof adopts structural waterproof design without any additional waterproof treatment. The interior and exterior walls and roofs have bright color, soft texture, flat panel surface, very harmonious with the steel skeleton of the house, which has a good decorative effect, and the interior decoration of the house is also very strong.
济南活动板房的施工
Construction of movable plank house in Jinan
1、地坪施工步骤
1. Floor construction steps
场地平整→ 碎石回填→ 5cm素砼垫层(C15)→ PVC防潮层→ 100厚砼浇注(C30)→面层
Site leveling → gravel backfilling → 5cm plain concrete cushion (C15) → PVC damp proof course → 100 thick concrete pouring (C30) → surface course

2、有关要求:
2. Relevant requirements:
a) 场地平整采用蛙式打夯机,平整宽度包括每边100cm的工作面。
a) Frog rammer is used for site leveling, and the leveling width includes working face of 100cm on each side.
b) 场地底板下采用25cm厚度的碎石回填,碎石回填的宽度包括每边100cm的工作面。
b) Under the site floor, 25cm thick gravel is used for backfilling, and the width of gravel backfill includes the working face of 100cm on each side.
c) 地坪浇捣所使用的砼,由商品砼搅拌站供应。砼的浇捣直接采用搅拌车输送。砼的浇捣应采取踏步向前推进,直浇捣完。
c) The concrete used for floor pouring and tamping shall be supplied by commercial concrete mixing station. Concrete pouring and tamping are directly transported by mixer truck. The concrete pouring and tamping shall be carried forward step by step until the pouring and tamping is completed.
d) 砼应浇捣密实,防止出现夹心层。
d) The concrete should be poured and compacted to prevent the occurrence of sandwich layer.
e) 砼表面处理做到“二压二平”。,按面标高用煤撬拍板压实,刮尺刮平;然后终凝前用木蟹打磨压实、整平,防止条基表面高低不平。
e) Concrete surface treatment to achieve "two pressure and two leveling". First of all, according to the surface elevation, the coal skid clapboard is used for compaction, and the scraping ruler is used for leveling; then, before the final setting, the wood crab is used to grind, compact and level to prevent the uneven surface of strip foundation.
f) 混凝土养护采取草袋覆盖浇水的方式。
f) Concrete curing adopts the method of straw bag covering and watering.
2.本工程的地质勘察报告显示,活动板房所座落的基础下无暗浜等松散土层,其面层有超出60cm厚的建筑道渣压实层,其表层土的地耐力大于100KN/m2.
2. According to the geological investigation report of the project, there is no loose soil layer such as dark Creek under the foundation where the movable plank house is located. The surface layer has a compaction layer of construction ballast more than 60cm thick, and the ground endurance of the surface soil is greater than 100kN / m2
根据活动板房的厂家资料,活动板房为轻质钢木行架结构,钢架间距900mm,梁为3号和2.5号角铁焊接桁架,立柱为2.5号方管,活动板房的楼层板为450mm宽,跨度为900mm配筋砼薄板。墙面吊顶为钢丝防火保温隔热轻质材料(珍珠岩)制成:墙面为900mm×900mm的薄型轻质板,简支搁置于木行架梁面上;吊顶为300mm宽900mm跨的轻质板,直接搁置于木行架的下弦杆上。屋面为波形水泥瓦。搂地面为15厚1:2.5水泥砂浆压光。
According to the manufacturer's information of the prefabricated house, the prefabricated house is a light steel and wood frame structure, with a steel frame spacing of 900mm, beams of No. 3 and No. 2.5 angle iron welded truss, column of No. 2.5 square tube, floor slab of the movable slab house is 450mm wide, span is 900mm, reinforced concrete thin plate. The wall ceiling is made of light-weight material (perlite) with fire-proof and thermal insulation of steel wire: the wall is made of 900mm × 900mm thin light-weight board, which is simply supported on the surface of wooden frame; the ceiling is a light-weight board with a width of 300 mm and a span of 900 mm, which is directly placed on the lower chord of the wooden frame. The roof is corrugated cement tile. 15 thick 1:2.5 cement mortar calendering is applied to the floor.
济南活动板房厂家
Jinan mobile board house factory
以上就是今天为大家介绍的关于济南活动板房施工方法及施工顺序的相关内容,希望对大家能有所帮助,如果大家想要了解更多内容可以电话联系我们或者关注我们的网站http://www.lxcaigang.com/,我们的工作人员会及时与大家取得联系去,期待您的来电。
The above is today's introduction about the construction method and construction sequence of Jinan prefabricated house, hoping to help you. If you want to know more, you can contact us by phone or pay attention to our website http://www.lxcaigang.com/ Our staff will contact you in time and look forward to your call.
